Overview
The ANT-6 is a multipurpose low-noise induction magnetometer designed for AMT and CSAMT work across a wide audio-frequency bandwidth. Its compact form factor, battery-powered operation, and stable transfer function make it a practical field sensor for crews that need strong performance from 0.1 Hz into the 10 kHz range.
Where It Fits
- AMT programs
- CSAMT surveys
- Broadband magnetic field acquisition
- Campaigns where compact, battery-powered sensors are preferred
Key Specifications
- Optimal frequency range:
0.1 Hz to 10 kHz - Sensitivity:
250 mV/nT - Noise at
1 Hz:240 fT/sqrt(Hz) - High-pass corner:
1 Hz - Low-pass corner:
10 kHz,3 pole - Length:
919 mm - Weight:
3 kg - Power supply:
3 x 9 V batteries - Supply current:
5.6 mA - Standard connector:
PT02A-4-8S
Why Customers Choose It
The ANT-6 is well suited when projects need wide-band audio-frequency coverage in a proven field package. It offers a strong balance of sensitivity, portability, and ease of deployment for everyday AMT and CSAMT operations.
